ODM Multi-Layer Plastic Sheet Extrusion Machine Manufacturers, Products

The inclined and horizontal multilayer co-extruder uses the latest technology and design to efficiently produce multilayer co-extruded sheets to meet the needs of various industries. With multiple extruders and laminated die heads, our inclined horizontal multilayer co-extruders can extrude and stack a wide range of different materials to form high-quality multilayer composite sheets. This equipment has the advantages of high production efficiency and stable product quality, which can help customers improve production efficiency, reduce costs and improve product quality.

Send Inquiry

Product Description

Product Specifications

Parameter	Value
Model	ECI-350
Capacity	200-350kg/h
Number of screws	1
Sheet material	PP PET PS PVC HIPS ABS
Sheet thickness	0.3-2.0mm
Screw diameter	120mm
L/D ratio	33:1
Main motor	110KW
Overall power	270Kw
Overall Dimension	L1.2W1.8H2.2
Voltage	380V 50HZ
Machine weight	21T

Product Advantages

The inclined horizontal multilayer co-extruder is an environment friendly and versatile device with the following advantages:

High manufacturing efficiency: The use of superior technological know-how and design, can successfully produce multi-layer co-extruded sheet, enhance manufacturing efficiency, retailer time and labor costs.

Strong versatility: Through multiple extruders and laminated die heads, a range of special substances can be co-extruded to produce multi-layer composite sheets with special houses and features to meet the various wishes of customers.

Stable and dependable quality: secure equipment design, correct manufacturing method control, to make certain steady product quality, in line with enterprise requirements and purchaser requirements.

Environmental safety and electricity saving: The use of superior manufacturing technological know-how and equipment, strength saving and environmental protection, in line with modern-day environmental safety requirements, limit the affect on the environment.

Perfect technical support: We supply a full range of technical help and after-sales provider to make certain that clients can completely recognize and function the equipment, attain environment friendly operation, and proceed to create value.

Product Uses

Horizontal multi-layer co-extruder is widely used in the following application scenarios in various industries:

Packaging industry: Covers the production of all kinds of packaging materials, such as food packaging film, pharmaceutical packaging film, cling film, and others to meet the diverse needs of the packaging industry for materials.
Construction industry: Can produce a variety of thermal insulation materials, waterproof materials, sound insulation materials, and other building materials to improve performance and functionality.
Automotive Industry: Such as automotive interior materials, body parts, sound insulation materials, and others which are necessary to elevate the automobile products’ quality and performance.
Electronic Industry: Like shell materials of electronic products, insulation materials, thermal conductivity materials, etc., which are used to satisfy electronic products towards material performance.
Medical Industry: Such as medical device pack materials, medical isolation materials, medical dressings etc., to make sure the safety and healthiness of medical products.

Operation Guide

The operation steps of a horizontal multi-layer co-extruder generally are the following main steps:

Preparation: Check if the equipment works regularly and prepare all needed raw materials and ancillary equipment.

Power-on order: Turning on the device by following the required sequence described by the operation manual to bring all parts into service, as, otherwise, any one component not in operation can render the machine useless.

Commissioning equipment: By the needs of production, re-adjust the extruder’s temperature, pressure, and other parameters to guarantee that the equipment should be able to normally produce required multi-layer co-extruded sheets.

Feeding and Extrusion: According to formula feeding various raw materials into the extruder, extruding through the extruder to forming multi-layer co-extruded sheet.

Laminating and cooling: The multilayer sheets are extruded through the die head of the lamination structure, stacked together, and then cooled and cured through the cooling device.

Cutting and packaging: Cut and pack the multilayer co-extruded sheet, and the final product is ready for use in any application.

Cleaning and maintenance: Clean and maintain the equipment after production is over, so that it may be continued for a long time in stable operation.

Frequently Asked Questions (FAQ)

What materials can the ECI-350 co-extruder process?

The ECI-350 co-extruder can successfully process a variety of sheet materials including PP, PET, PS, PVC, HIPS, and ABS.

What is the production capacity and thickness capability of this machine?

It has a production capacity of 200-350kg/h and supports a sheet thickness range of 0.3mm to 2.0mm.

What are the main advantages of this inclined horizontal co-extruder?

It provides high manufacturing efficiency, strong versatility for different composite sheets, stable output quality, energy-saving environment-friendly performance, and complete technical support.

Which industries widely use this co-extruder?

It is extensively used in the Packaging Industry (films), Construction Industry (insulation/waterproof materials), Automotive Industry (interior/body parts), Electronic Industry (shell/insulation materials), and Medical Industry (device packaging/dressings).

Why is the specific power-on sequence important in the operation guide?

Turning on the components in the required sequence ensures that every part is fully operational. If any single component is not in service, it can render the entire machinery useless.

What is required for the maintenance of the co-extruder?

After production is over, you must clean and maintain the equipment to ensure long-term, stable, and efficient operation.
